STEERING GEAR
POWER STEERING
37-7
STEERING GEAR
M2370003000079
• Using the following parts have contributed to
reduce weight: aluminium steering gear and link-
age valve housing, plastic tie-rod bellows, and
hollow-type tie-rod stud.
• The installation accuracy, rigidity and steering
stability have been improved by using an eye
bushing, which secures the steering gear to the
crossmember.
AC211252
AB
TIE-ROD END
GEAR HOUSING
GEAR HOUSING
VALVE HOUSING
TIE-ROD BELLOWS
CROSSMEMBER
CROSSMEMBER
HOLLOW
INNER PIPE
BUSHING
