GENERAL DESCRIPTION
ENGINE
11A-2
GENERAL DESCRIPTION
M2112000100233
The model 4G63-DOHC engine, based on the 4G63
single-overhead-camshaft engine has four valves
per cylinder and two camshafts in the cylinder head
(double-overhead-camshaft configuration).
GENERAL SPECIFICATIONS
ITEM 4G63-DOHC-T/C
Total displacement cc
1,997
Combustion chamber Pent roof type
Bore × Stroke mm 85.0 × 88.0
Compression ratio 8.8
Camshaft arrangement DOHC-16 valve
Valve timing Intake opening BTDC 17°
Intake closing ABDC 59°
Exhaust opening BBDC 57°
Exhaust closing ATDC 15°
Maximum output kW/rpm (HP/r/min) 202/6,500 (271/6,500)
Maximum torque N⋅m/rpm (lbs-ft/r/min) 37/3,500 (273/3500)
Lash adjuster Equipped
