Codes in parentheses indicate bulb types.
NOTE
l
The
high-mounted stop lamp uses LEDs rath-
er than bulbs. For repair and replacement, we
recommend you to consult a specialist.
Inside
E01003401547
1- Cargo room lamp: 8 W
2-
Rear room lamp
*
: 8 W
3-
Front room & map lamps
*
: 8 W
*
if so equipped
Headlamps (low beam, except for vehi-
cles
with high intensity discharge head-
lamps)
E01009300310
1. For petrol-powered vehicles equipped with
turbocharger, when replacing the bulb on the
left side, remove the bolt (A) holding down
the relay box and move the relay box to-
wards the rear of the vehicle.
*: Front of the vehicle
2. For petrol-powered vehicles equipped with
turbocharger, when replacing the bulb on the
right side, lift up the engine coolant reservoir
(B).
*: Front of the vehicle
Maintenance
8-29
8
