5. PARAMETERS
5 - 54
5.2.6 Extension setting 3 parameters ([Pr. PF_ _ ])
Control
mode
No./symbol/
name
Setting
digit
Function
Initial
value
[unit]
P S T
PF09
*FOP5
Function
selection F-5
_ _ _ x Electronic dynamic brake selection
0: Automatic (enabled only for specified servo motors)
2: Disabled
Refer to the following table for the specified servo motors.
0h
Series Servo motor
HG-KR HG-KR053, HG-KR13, HG-KR23, HG-KR43
HG-MR HG-MR053, HG-MR13, HG-MR23, HG-MR43
HG-SR HG-SR51, HG-SR52
_ _ x _ For manufacturer setting 0h
_ x _ _ 0h
x _ _ _ 0h
PF15
DBT
Electronic
dynamic
brake
operating
time
Set an operating time for the electronic dynamic brake.
Setting range: 0 to 10000
2000
[ms]
PF21
DRT
Drive
recorder
switching
time setting
Set a drive recorder switching time.
When a USB communication is cut during using a graph function or a graph function
is terminated, the function will be changed to the drive recorder function after the
settling time of this parameter.
When a value from "1" to "32767" is set, it will switch after the setting value.
When "0" is set, it will switch after 600 s.
When "-1" is set, the drive recorder function is disabled.
Setting range: -1 to 32767
0
[s]
PF23
OSCL1
Vibration
tough drive -
Oscillation
detection
level
Set a filter readjustment sensitivity of [Pr. PB13 Machine resonance suppression
filter 1] and [Pr. PB15 Machine resonance suppression filter 2] while the vibration
tough drive is enabled.
However, setting "0" will be 50%.
Example: When you set "50" to the parameter, the filter will be readjusted at the time
of 50% or more oscillation level.
Setting range: 0 to 100
50
[%]
PF24
*OSCL2
Vibration
tough drive
function
selection
_ _ _ x Oscillation detection alarm selection
Select alarm or warning when an oscillation continues at a filter readjustment
sensitivity level of [Pr. PF23].
The digit is continuously enabled regardless of the vibration tough drive in [Pr.
PA20].
0: [AL. 54 Oscillation detection] will occur at oscillation detection.
1: [AL. F3.1 Oscillation detection warning] will occur at oscillation detection.
2: Oscillation detection function disabled
0h
_ _ x _ For manufacturer setting 0h
_ x _ _ 0h
x _ _ _ 0h
