9 OUTLINE DRAWINGS
9 - 7
(f) MR-J4-500A(-RJ)
[Unit: mm]
105
93 66
Approx. 25
7.5 235
200
6
Approx. 80
Approx. 28
Approx.
38.5
A
pprox.
34
Cooling fan
exhaust
Intake
With
MR-BAT6V1SET
2-φ6 mounting hole
250
7.5
6
PE
TE1
TE3
TE4
TE2
Mass: 4.0 [kg]
L2
N-
P3
L11
L21
P4
L3
L1
C
D
P+
PE
Terminal
TE2
TE1
V
W
U
TE3
TE4
TE2
TE1
TE3
TE4
PE
Screw size: M3.5
Tightening torque: 0.8 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
93 ± 0.5
Approx. 105
Approx. 6Approx. 6
4-M5 screw
Approx. 7.5
235 ± 0.5
Approx. 250
Mounting hole process drawing
Approx. 7.5
