Mitsubishi MR-J4-40A

10. CHARACTERISTICS
10 - 2
The following graphs show overload protection characteristics.
(Note 1, 2) Load ratio [%]
1000
100
10
1
0.1
100 200 300 350
0
50 150 250
Operating
Servo-lock
Operation time [s]
1000
100
10
1
0.1
100 200 300 400
0 50 150 250 350
Load ratio [%]
(Note 1, 2, 3)
Servo-lock
Operating
Operation time [s]
Characteristics a Characteristics b
1000
100
10
1
0.1
100 200 300 400
0 50 150 250 350
Load ratio [%]
(Note 1, 3)
Servo-lock
Operating
Operation time [s]
1000
100
10
1
0.1
100200300400
0 50 150 250 350
Load ratio [%]
(Note 1, 3)
Servo-lock
Operating
Operation time [s]
Characteristics c Characteristics d
