3. SIGNALS AND WIRING
3 - 27
(Note 2) I/O signals in control modes
Pin No.
(Note 1)
I/O
P P/S S S/T T T/P
Related parameter
1 P15R P15R P15R P15R P15R P15R
2 I -/VC VC VC/VLA VLA VLA/-
3 LG LG LG LG LG LG
4 O LA LA LA LA LA LA
5 O LAR LAR LAR LAR LAR LAR
6 O LB LB LB LB LB LB
7 O LBR LBR LBR LBR LBR LBR
8 O LZ LZ LZ LZ LZ LZ
9 O LZR LZR LZR LZR LZR LZR
10 I PP PP/- -/PP
11 I PG PG/- -/PG
12 OPC OPC/- -/OPC
13
14
15 I SON SON SON SON SON SON Pr. PD03/Pr. PD04
16 I -/SP2 SP2 SP2/SP2 SP2 SP2/- Pr. PD05/Pr. PD06
17 I PC PC/ST1 ST1 ST1/RS2 RS2 RS2/PC Pr. PD07/Pr. PD08
18 I TL TL/ST2 ST2 ST2/RS1 RS1 RS1/TL Pr. PD09/Pr. PD10
19 I RES RES RES RES RES RES Pr. PD11/Pr. PD12
20 DICOM DICOM DICOM DICOM DICOM DICOM
21 DICOM DICOM DICOM DICOM DICOM DICOM
22 O INP INP/SA SA SA/- -/INP Pr. PD23
23 O ZSP ZSP ZSP ZSP ZSP ZSP Pr. PD24
24 O INP INP/SA SA SA/- -/INP Pr. PD25
25 O TLC TLC TLC TLC/VLC VLC VLC/TLC Pr. PD26
26
27 I TLA
(Note 3)
TLA
(Note 3)
TLA
(Note 3)
TLA/TC
TC TC/TLA
28 LG LG LG LG LG LG
29
30 LG LG LG LG LG LG
31
32
33 O OP OP OP OP OP OP
34 LG LG LG LG LG LG
35 I NP NP/- -/NP
36 I NG NG/- -/NG
37
38
39
40
41 I CR CR/SP1 SP1 SP1/SP1 SP1 SP1/CR Pr. PD13/Pr. PD14
42 I EM2 EM2 EM2 EM2 EM2 EM2
43 I LSP LSP LSP LSP/- -/LSP Pr. PD17/Pr. PD18
44 I LSN LSN LSN LSN/- -/LSN Pr. PD19/Pr. PD20
45 I LOP LOP LOP LOP LOP LOP Pr. PD21/Pr. PD22
46 DOCOM DOCOM DOCOM DOCOM DOCOM DOCOM
47 DOCOM DOCOM DOCOM DOCOM DOCOM DOCOM
48 O ALM ALM ALM ALM ALM ALM
49 O RD RD RD RD RD RD Pr. PD28
50
Note 1. I: Input signal, O: Output signal
2. P: Position control mode, S: Speed control mode, T: Torque control mode, P/S: Position/speed control change
mode, S/T: Speed/torque control change mode, T/P: Torque/position control change mode
3. TLA will be available when TL (External torque limit selection) is enabled with [Pr. PD03] to [Pr. PD22].
