11
When appears on the display, do not perform pairing. The power may be turned off
in the middle of pairing, which may lose the pairing information.
When using multiple wireless remote controllers in one ecodan system, be sure to set
different address for each remote controller.
When the pairing process has been success-
fully performed, " " is shown on the remote
controller and green LED steadily lights on
the wireless receiver.
<Pairing is successful>
Lighting (green)
Blinking (orange)
Press or button to set the mode number
to “1” and press button.
When button is pressed in the middle of
setting, the screen returns to the previous
indication.
Press or button to select a pairing ad-
dress, and press button to set the address.
" " (no setting) is displayed initially. Choose a
number from 1 to 8.
After pressing button, the wireless remote
controller starts communication with the wire-
less receiver.
To Next Page
