Mitsubishi PLA-A12BA

43
Outdoor heat exchanger
Thermistor
(TH3)
Thermistor
(TH6)
Distributor
Service
port
(check)
Accumulator
Compressor
Refrigerant GAS pipe
15.88A({5/8)
Refrigerant LIQUID pipe
9.52A({3/8)
Stop valve
(with service port)
Service
port
(check)
High pressure
protect switch
Refrigerant flow in cooling
Linear expansion valve
Ball valve
(#50)
Strainer
(#100)
Strainer
(#100)
Strainer
Thermistor
(TH32)
Bypass valve
PUY-A12NHA3(-BS) PUY-A18NHA3(-BS)
PUY-A42NHA3(-BS)
Outdoor heat exchanger
Thermistor
(TH3)
Thermistor
(TH6)
Distributor
Service port
(Check)
Accumulator
Compressor
Refrigerant GAS pipe
12.7A({1/2)
Refrigerant LIQUID pipe
6.35A({1/4)
Stop valve
High pressure
protect switch
Linear expansion valve
Refrigerant flow in cooling
Stop valve
(with service port)
(#50)
Strainer
(#100)
Strainer
(#100)
Strainer
Thermistor
(TH32)
Service
port
(check)
Accumulator
Compressor
Refrigerant GAS pipe
15.88A({5/8)
Refrigerant LIQUID pipe
9.52A({3/8)
Service
port
(check)
High pressure
protect switch
Thermistor
(TH4)
Refrigerant flow in cooling
Stop valve
(with service port)
Linear expansion valve
Ball valve
(#50)
Strainer
Strainer
(#100)
Strainer
(#100)
Strainer
(#100)
Low pressure protect
switch
Outdoor heat exchanger
Thermistor
(TH3)
Thermistor
(TH6)
Distributor
PUY-A24NHA3(-BS) PUY-A30NHA3(-BS) PUY-A36NHA3(-BS)
Unit: mm (inch)
