－13－
(4) Press the Ｂ key, then operation mode changes winding mode show as above picture.
(5) Pass through the thread from the thread stand (NO.3) as shown on the below figure then,
wind the thread to the empty bobbin (NO.5) in the arrow mark “a” direction couple times
and insert the bobbin (NO.5) into the bobbin winder (NO.6).
(6) Push the adjust lever (NO.6) in the arrow mark “b” direction.
(7) Step on the foot switch (NO.8). The thread is kept winding to the bobbin (NO.5) while the
foot switch is stepping on.
(8) When the bobbin becomes full of the thread, the adjust lever (NO.7) is returned to the
original position.
(9) Release the foot switch, and press Ｈ key (NO.2). Then operation mode returns to the
normal mode.
(10) To wind the bobbin thread during the sewing operation, carry out above (5) and (6)
procedure then, bobbin winding is performed automatically.
(11) Please refer [7-7. Adjustment of the bobbin winder] on this manual for the adjustment.
b
a
6
5
4
7
8
9
To Next Page
