5 DATA USED FOR POSITIONING CONTROL
Setting Value, setting range
Value set with peripheral device
Setting value buffer memory
address
Servo amplifier setting invalid ( : Invalid, : Valid)
MR-
H-BN
MR-
H-BN4
MR-
J2-B
MR-
J2S-B
MR-
J2-Jr
MR-
J2M-B
Value set with sequence program
Default
value
Axis 1 Axis 2 Axis 3 Axis 4
3
Monitor 2
output setting
0
0
Monitor 1
output setting
1: is used to set up the setting
value.
(Hexadecimal)
H
0001
H
30122 30222 30322 30422
Servo forced
stop selection
0
Serial encoder
cable setting
Low acoustic noise
mode selection
1: is used to set up the setting
value.
(Hexadecimal)
H
0000
H
30123 30223 30323 30423
2: Set the parameter value and switch power off once (The parameter is transferred to servo amplifier from QD75), then switch it on
again to make that parameter setting valid.
3: Don't change setting value "0001
H
" by any means.
