15 - 19
MELSEC-Q
15 TROUBLESHOOTING
Related buffer memory
address
Axis 1 Axis 2 Axis 3 Axis 4
Set range
(Setting with sequence program)
Remedy
Same as error codes 515 to 516
Correct the control system or parameter.
(Refer to section 9.1.6, 9.2.20)
Correct the sub address (arc address).
(Refer to section 9.2.10)
Refer to section 5.3
"List of positioning data"
<Positioning address/movement
amount>
• unit [mm] [PLS] [inch]
–2147483648 to 2147483647
(Unit [degree]) cannot be set.
<Arc address>
–2147483648 to 2147483647
Correct the end address (positioning address).
(Refer to section 9.2.10)
Same as in error codes 525 to 526.
Correct the center point address (arc address).
(Refer to section 9.2.11)
Same as in error codes 504, 506.
Correct the positioning address.
(Refer to section 9.2.16, 9.2.17, 9.2.18)
Refer to sections 5.3
"List of positioning data"
and 5.4 "Block start data"
—
In the error history, check the axis where the error
other than this error occurred, and remove the error
factor. Correct the block start data and positioning data.
