7 - 30 7 - 30
MELSEC-Q
7 PARAMETER SETTING
[Set values of default assignment parameters]
Default Assignment Parameter Setting Items
Assignment Name
Buffer Memory
Address
Device code
(Device symbol)
Head device
number
Head MODBUS
R
device number (*1)
Assignment
points
Coil assignment 1 0900H to 0903H 009DH (Y) 0000H 0 8192
Coil assignment 2 0904H to 0907H 0090H (M) 0000H 8192 8192
Coil assignment 3 0908H to 090BH 0091H (SM) 0000H 20480 2048
Coil assignment 4 090CH to 090FH 0092H (L) 0000H 22528 8192
Coil assignment 5 0910H to 0913H 00A0H (B) 0000H 30720 8192
Coil assignment 6 0914H to 0917H 0093H (F) 0000H 38912 2048
Coil assignment 7 0918H to 091BH 00A1H (SB) 0000H 40960 2048
Coil assignment 8 091CH to 091FH 0094H (V) 0000H 43008 2048
Coil assignment 9 0920H to 0923H 0098H (S) 0000H 45056 8192
Coil assignment 10 0924H to 0927H 00C0H (TC) 0000H 53248 2048
Coil assignment 11 0928H to 092BH 00C1H (TS) 0000H 55296 2048
Coil assignment 12 092CH to 092FH 00C6H (SC) 0000H 57344 2048
Coil assignment 13 0930H to 0933H 00C7H (SS) 0000H 59392 2048
Coil assignment 14 0934H to 0937H 00C3H (CC) 0000H 61440 2048
Coil assignment 15 0938H to 093BH 00C4H (CS) 0000H 63488 2048
Coil assignment 16 093CH to 093FH 0000H
0000
H 0 0
Input assignment 1 0940H to 0943H 009CH (X) 0000H 0 8192
Input assignment 2 to 16 0944H to 097FH 0000H
0000
H 0 0
Input register assignment 1 to 16 0980H to 09BFH 0000H
0000
H 0 0
Holding register assignment 1 09C0H to 09C3H 00A8H (D) 0000H 0 12288
Holding register assignment 2 09C4H to 09C7H 00A9H (SD) 0000H 20480 2048
Holding register assignment 3 09C8H to 09CBH F000H
5000
H 22528 4096
Holding register assignment 4 09CCH to 09CFH 00B4H (W) 0000H 30720 8192
Holding register assignment 5 09D0H to 09D3H 00B5H (SW) 0000H 40960 2048
Holding register assignment 6 09D4H to 09D7H 00C2H (TN) 0000H 53248 2048
Holding register assignment 7 09D8H to 09DBH 00C8H (SN) 0000H 57344 2048
Holding register assignment 8 09DCH to 09DFH 00C5H (CN) 0000H 61440 2048
Holding register assignment 9 to 16 09E0H to 09FFH 0000H
0000
H 0 0
*1: Use the following expression to find the set value of the head MODBUS
R
device number.
Head MODBUS
R
device number = Last 5 digits of MODBUS
R
device number to be set - 1
POINT
The programmable controller CPU device range varies depending on the
programmable controller CPU.
(Refer to QCPU User's Manual (Function Explanation, Program Fundamentals))
Depending on the programmable controller CPU, some of the default assignment
parameter range may not be usable.
In such a case, observe either of the following not to access the devices outside the
allowable range.
Set the MODBUS
R
device assignment parameters.(Refer to Section 7.4)
Make the setting within the allowable programmable controller CPU device
range.
Do not access any device outside the allowable range when using the default
assignment parameters.
