7 - 6 7 - 6
MELSEC-Q
7 PARAMETER SETTING
7.2 Basic Parameters
7.2.1 Basic parameters details
The basic parameters are classified into the following three types.
(1) TCP/UDP/IP setting
Address Parameter Name Setting Range Initial Value
0000H
(0)
TCP ULP timer value
Set time = set value 500ms
2 to 2400 60
0001H
(1)
TCP zero window timer value
Set time = set value 500ms
2 to 2400 20
0002H
(2)
TCP resend timer value
Set time = set value
500ms
2 to 2400 20
0003H
(3)
TCP end timer value
Set time = set value 500ms
2 to 2400 40
0004H
(4)
IP reassembly timer value
Set time = set value
500ms
1 to 2399 10
0005H
(5)
TCP/UDP/IP
monitoring
timer
Split reception monitoring timer value
Set time = set value 500ms
2 to 2400 60
0006H
(6)
KeepAlive
0: Not used
1: Used
1
0007H
(7)
KeepAlive start timer value
Set time = set value 500ms
1 to 32767 1200
0008H
(8)
KeepAlive interval timer value
Set time = set value
500ms
1 to 32767 20
0009H
(9)
KeepAlive
KeepAlive resend count 1 to 10 3
000AH
(10)
Router relay function
0: Not used
1: Used
0
000BH to 000CH
(11 to 12)
Subnet mask pattern
C0000000H to
FFFFFFFCH
FFFFFF00
H
000DH to 000EH
(13 to 14)
Default router IP address
Refer to Section
7.2.2 (3) (c)
00000000
H
000FH
(15)
Number of routers set 0 to 8 0
0010H to 0011H
(16 to 17)
Subnet address
Refer to Section
7.2.2 (3) (e)
00000000
H
0012H to 0013H
(18 to 19)
Router information 1
Router IP address
Refer to Section
7.2.2 (3) (f)
00000000
H
0014H to 002FH
(20 to 47)
Routing
information
Router information 2 to 8 (Same as router information 1)
