8 UTILITY PACKAGE (GX Configurator-MB)
Monitor Item
Buffer memory
address
Reference
section
ICMP packet reception count
0E30
H to 0E31H
(3632 to 3633)
Count of ICMP packet reception discarded due to sum check
error
0E32H to 0E33H
(3634 to 3635)
Total number of sent ICMP packets
0E34
H to 0E35H
(3636 to 3637)
Total number of ICMP echo request received
0E36
H to 0E37H
(3638 to 3639)
Total number of ICMP echo reply sent
0E38
H to 0E39H
(3640 to 3641)
Total number of ICMP echo request sent
0E3A
H to 0E3BH
(3642 to 3643)
ICMP
Total number of ICMP echo reply received
0E3C
H to 0E3DH
(3644 to 3645)
TCP packet reception count
0E50
H to 0E51H
(3664 to 3665)
Count of TCP packet reception discarded due to sum check error
0E52
H to 0E53H
(3666 to 3667)
TCP
Total number of sent TCP packets
0E54
H to 0E55H
(3668 to 3669)
UDP packet reception count
0E70
H to 0E71H
(3696 to 3697)
Count of UDP packet reception discarded due to sum check error
0E72
H to 0E73H
(3698 to 3699)
UDP
Total number of sent UDP packets
0E74
H to 0E75H
(3700 to 3701)
Framing error count
0E84
H to 0E85H
(3716 to 3717)
Overflow count
0E86
H to 0E87H
(3718 to 3719)
Receive
error
CRC error count
0E88
H to 0E89H
(3720 to 3721)
Section 11.3.1
