8 UTILITY PACKAGE (GX Configurator-MB)
[Setting items]
For the automatic communication parameter setting, set the data format or
setting range value of each item in the Setting value column, and click the
End setup button to save the set values.
Setting Item
Buffer memory
address
Reference
section
Target station IP address
0200
H to 0201H
(512 to 513)
Module ID
0202
H
(514)
Repeat interval timer value
0203
H
(515)
Response monitoring timer value
0204
H
(516)
Type specification of the target MODBUS
R
device
0205
H
(517)
Head buffer memory address
0206
H
(518)
Target MODBUS
R
device head number
0207
H
(519)
Read
setting
Access points
0208H
(520)
Head buffer memory address
0209
H
(521)
Target MODBUS
R
device head number
020A
H
(522)
Automatic
communication
parameter 1
Write
setting
Access points
020B
H
(523)
Automatic
communication
parameter 2 to
64
(Same as in automatic communication parameter 1)
020C
H to 04FFH
(524 to 1279)
Section 7.3
POINT
After the automatic communication parameters have been written to the
programmable controller CPU, the automatic communication function is operated
when the programmable controller is powered ON from OFF or the programmable
controller CPU is reset (with the programmable controller CPU’s RUN/STOP switch
set to RUN).
