9 - 2
9 - 2
MELSEC-Q
9 PROGRAMMING
(3) Timing
charts for basic parameter
setting
(a)
W
hen setting is completed normally
Y1
X1
X3
X2
Executed by QJ71MT91
Executed by sequence program
OFF
ON
OFF
OFF
OFF
ON
X0
OFF
ON
ON
0C10
H
Parameter creation
Module READY
Basic parameter
setting request
Basic parameter
setting, normally
completed
Basic parameter
setting, error
completed
Basic parameter
setting existence
Basic parameter
error code storage
area
Basic parameter
creation
Basic parameter
setting, normally
completed
Error code
clear
(b)
W
hen setting
is completed with an error
Y1
X1
X3
X2
OFF
ON
ON
OFF
OFF
OFF
ON
X0
OFF
ON
ON
Executed by QJ71MT91
Executed by sequence program
0C10
H
ON
Parameter creation
Module READY
Basic parameter
setting request
Basic parameter
setting, normally
completed
Basic parameter
setting, error
completed
Basic parameter
setting existence
Basic parameter
error code storage
area
Basic parameter
correction
Basic parameter
creation (error)
Basic parameter
setting, error
completed
Basic parameter
setting, normally
completed
Error code
clear
Error code
storage
9
