9 - 14 9 - 14
MELSEC-Q
9 PROGRAMMING
(2) Parameter setting details
The following table gives the setting details of the parameters set in the program
example.
(a) Basic parameters
Setting Item Buffer Memory Address Set Value
TCP ULP timer value 0000H (0) 60 (30s)
TCP zero window timer value 0001H (1) 20 (10s)
TCP resend timer value 0002H (2) 20 (10s)
TCP end timer value 0003H (3) 40 (20s)
IP reassembly timer value 0004H (4) 10 (5s)
TCP/UDP/IP
monitoring timer
Split reception monitoring timer value 0005
H (5) 60 (30s)
KeepAlive 0006H (6) 1 (Used)
KeepAlive start timer value 0007H (7) 1200 (600s)
KeepAlive interval timer value 0008H (8) 20 (10s)
KeepAlive
KeepAlive resend count 0009
H (9) 3
Router relay function 000AH (10) 0 (Not used)
Subnet mask pattern 000BH to 000CH (11 to 12)
FFFFFF00
H
(255.255.255.0)
Default router IP address 000DH to 000EH (13 to 14)
00000000
H
(0.0.0.0)
Number of routers set 000FH (15) 0
Subnet address 0010H to 0011H (16 to 17)
00000000
H
(0.0.0.0)
Routing information
Router
information 1
Router IP address 0012H to 0013H (18 to 19)
00000000
H
(0.0.0.0)
GX Developer
connection
information setting
Number of TCP connectors for GX
Developer connection
0030
H (48) 1
Local slave station port No. 0110H (272) 502
Target slave port No. for automatic
communication function
0111
H (273) 502
CPU response monitoring timer value 0114H (276) 10
IP address 0115H to 0116H (277 to 278)
C0010002
H
(192.1.0.2)
MODBUS
R
/TCP
setting
Preferred node
specification 1
Number of connections 0117
H (279) 2
