9 PROGRAMMING
<<Handling of automatic communication error>>
<<Refresh processing: Automatic communication function buffer output area>>
Module
READY
Automatic
comm.
operation
status
Module
READY
Automatic
comm.
operation
status
Automatic
comm.
error
status
Automatic
comm.
error
status
Automatic
comm.
error
status
REMFR
instruction
completion
REMFR
instruction
completion
REMFR
instruction
result
REMFR
instruction
completion
REMFR
instruction
result
REMFR
instruction
completion
REMTO
instruction
completion
REMFR
instruction
result
REMTO
instruction
completion
REMTO
instruction
completion
REMFR
instruction
completion
REMTO
instruction
result
Take corrective action for error completion, referring to Q
Corresponding MELSECNET/H Network System Reference
Manual (Remote I/O Network).
Take corrective action for error completion, referring to Q
Corresponding MELSECNET/H Network System Reference
Manual (Remote I/O Network).
Turns ON External output (Y40)
when automatic communication
parameter 1 is invalid.
Acquires error code when
automatic communication
parameter 1 is invalid.
Turns ON External output (Y41)
when automatic communication
parameter 2 is invalid.
Acquires error code when
automatic communication
parameter 2 is invalid.
Turns OFF automatic
communication operation status
for automatic communication
parameter 1 (D4000.0).
Turns OFF External output
(Y41) when automatic
communication is normal.
Turns OFF automatic
communication operation status
for automatic communication
parameter 2 (D4000.1).
Handling of Z.REMFR
instruction error
Refreshes automatic
communication function buffer
output area.
Handling of Z.REMTO
instruction error
Acquires automatic
communication operation status
and automatic communication
error code at automatic
communication error.
Turns OFF External output
(Y40) when automatic
communication is normal.
