Mitsubishi QJ71MT91

11 - 45 11 - 45
MELSEC-Q
11 TROUBLESHOOTING
(7) Change the "PING test execution request" current value back to "Not requested".
Because the "PING test execution request" current value does not automatically
return to "Not requested" on completion of the PING test, it must be manually
changed to "Not requested" after the PING test is completed,.
Select "Not requested" in the "PING test execution request" setting field and click
the Execute test button.
When the processing is completed, a "Completed." message appears.
(8) Confirm the "PING test execution request" current value.
The "PING test execution request" current value must be as shown below.
• "PING test execution request" current value
"Not requested"
• "PING test completed" current value
"OFF"
