Mitsubishi SRK35ZS-S

-
88
-
'16 • SCM-T-199
4. DRILLING HOLE AND FIXTURE OF SLEEVE
When drilling the wall that contains a metal lath, wire lath or metal plate, be sure to use sealing plate, sleeve and inclination plate (Locally procured parts).
5
ø65
Indoor side Outdoor side
(a) Sleeve
Top
Thickness of the wall + 1.5cm
Cut
Indoor side Outdoor side Installed state
Turn to tighten
(b) Sealing plate
(a) Sleeve
(c) Inclination plate
(1) Drill a hole with hole
core drill.
(2) Cut sleeve to adjust to wall
thickness. In case of rear piping draw out, cut off the lower and the right side portions of the sleeve collar.
(3) Fix sealing plate, sleeve
and inclination plate.
5. ELECTRICAL WIRING WORK
• Before installation, make sure that the power source complies with the air-conditioner’s power
specication.
• Carry out electrical wiring work according to following guidelines. 1. Preparing cable (1) Selecting cable
Selecttheconnectingcableinaccordancewiththespecicationsmentionedbelow. 4-core* 1.5mm
2
conformed with 60245 IEC57 (CENELEC H05RN-F)
* 1 Earth wire is included (Yellow/Green).
(2) Arrange each wire length as shown below.
Make sure that each wire is stripped 10mm from the end.
<Connecting cable> <Wire end>
40mm or more
Earth wir
e
30mm or more
10mm
(3) Attach round crimp-type terminal to each wire as shown in the below.
Selectthesizeofroundcrimp-typeterminalafterconsideringthespecicationsofterminalblock and wire diameter.
10mm
Round crimp-type terminal
Sleeve
2.Connectingcable (1) Open the air inlet panel. (2) Remove the lid. (3) Remove the cable clamp. (4) Connect the connecting wires to the terminal block. (5) Fix the connecting cable by cable clamp. (6) Fix the lid. (7) Close the air inlet panel.
NOTE
Take care not to confuse the terminal numbers for indoor and outdoor connections.
Lid
Terminal block
Cable clamp
The screw of the lid is
tightened securely.
(e) Connecting cable
• Earth wire shall be Yellow/Green (Y/G) in color and longer than other wires
for safety reason.
CAUTION
Incorrectwiringconnectioncancausemalfunctionorre.
CAUTION
After passing the wirings and pipes through the hole, completely seal the hole on the wall with putty to prevent water leakage.
(d) Putty
(d) Putty
