8
Assembly Information
The Pulsar Cutter is shipped with the “A” Frame and Brace with fastening hardware packaged,
bolted to the cutter deck
The smaller Cutter with a lighter gearbox, have a PTO shaft with a shearbolt. This PTO has a
large ‘bell’ on one end, covering the yoke and shearbolt.
The larger Cutter with a heaver gearbox, have a PTO shaft with a slip clutch and a PTO Guard
bolted on the gearbox. These guards are shipped, bolted on upside down on the gearbox.
Upon Receiving:
Unpack the parts and using preceding page (decal location) as reference. The lower “A” Frame
pivots on a bushing, fastened with carriage bolts. Each end of the brace is bolted with a bolt
and locknut. After tightening, back the nut up 1/2 turn to allow for free pivoting action of these
parts.
Cutters with larger gearbox:
The PTO Guard is bolted on with 4 metric bolts. Use a 13mm wrench to remove the bolts and
turn the Guard right side up, with the removable shield on top. These parts are secured to each
other with one lynch pin.
WARNING !
Always block cutter securely before working on or under cutter.
