MK Martin PULSAR PLUS - Gearbox LF 227 J

16
Pulsar Cutter LF 227J Gearbox
Item
#
Part # Description Qty
1 0.227.0301.00 Casting 1
2 0.238.6001.00 Gear 1
3 8.0.9.00143 Roller Bearing 2
4 0.709.7500.00 Shim Kit 2
5 8.5.2.00332 Snap Ring 2
6 0.121.7101.00 Oil Cap 1
7 0.227.2001.00 Input Shaft 1
8 8.7.1.02348 Dust lip 1
9 0.227.1301.00 Cover 1
10 8.6.5.00006 3/8 Plug 1
11 8.1.1.00054 Bolts 10m x 20 4
12 0.238.5001.00 Pinion 1
13 8.5.1.01084 Snap Ring 1
14 0.252.7525.00 Shim 1
15 8.0.9.00469 Roller bearing 2
16 0.712.7500.00 Shim kit 1
Item
#
Part # Description Qty
17 0.227.3002.00 Output Shaft 1
18 0.132.7107.00 Castle nut 1
19 8.4.7.02265 Cotter Pin 1
20 0.285.7510.00 Shim 1
21 8.2.2.00555 Castle Nut 1
22 8.7.1.01107 Dust Lip 1
23 0.139.7100.00 Washer 1
25 0.139.7101.00 Bolt Washer 1
26 8.6.5.00203 1/2 Plug 1
251 8.4.7.00146 Cotter Pin 1
