23
CHOP CUTTING
A Chop Cut is performed by cutting completely through an object in one pass.
MK-2000 ELECTRIC SAW ADJUSTMENT & OPERATION
(A)
Set the adjustable Cutting Guide to the
desired length indicated on the side of the
Ruler/Stop closest to the Wooden Strip.
Tighten thumbscrew.
(B)
Place the masonry piece onto
the movable Cutting Table.
(C)
Verify the masonry piece is seat-
ed against the Ruler/Stop and
the adjustable Cutting Guide.
(D)
Place the ON/OFF Switch in the
ON position.
(E)
Open the Cooling Flow Control Valve
and adjust cooling ow. Verify cooling
ow exists on both sides of the blade.
Skip step E, if cutting dry.
NOTE:
Cut in smooth even strokes; do not force the saw to cut.
(F)
Position the masonry piece
below the Blade.
(G)
Lower the Cutting Head to
begin the cut.
(H)
Continue lowering the Cutting
Head until the cut is complete;
raise the cutting head when the cut
is complete. Turn off the machine.
CAUTION
