MK MK-2000 - Exploded View & Parts List

42
MK-2000 ELECTRIC SAW EXPLODED VIEW & PARTS LIST
ITEM DESCRIPTION PART # QTY.
1 BEARING, CUTTING HD PIV 140004 2
2 BAR, ADJUSTMENT 150585 1
3 PIN, SLOTTED SPRING, 3/8 X 1-3/4 151358 1
4 WASHER, LOCK, SPLIT, 5/16 151747 4
5 SCREW, 5/16-18 X 1-1/2 HEX HEAD MACHINE 152467 4
6 BUSHING, FLANGE, 1/2X5/8X1 156441 2
7 HOUSING, PIVOT SHAFT 157979 1
8 HEAD, CUTTING (COMP) 160346 1
9 CLAMP, CUTTING HEAD (COMP) 160397 2
6.67±.06
1
2
3
4
5
6
7
8
9
Motor Mount Part # 160966
