MK-2000 ELECTRIC SAW PARTS LIST
ITEM DESCRIPTION PART # QTY.
1 HANDLE, BRICKSAW 139931 1
2 KEY, 3/16 SQ X 1-1/8 150344 2
3 STUD, BLD GUARD 150581 1
4 STRAP, MOTOR ADJ 150584 1
5 CASTING, 2000, BLT GRD INNR-COMP 150590 1
6 BLT GRD OUTR-COMP 150591 1
7 SCREW, HEX HD, CAP, 5/16-18X1-3/4 150919 2
8 WASHER, FLAT, SAE, 3/8 150923 1
9 WASHER, LOCK, SPLIT, 5/16 151747 2
10 WASHER, FLAT, SAE, 5/16 151754 8
11 WASHER, FLAT, SAE, 1/4 151915 3
12 SCREW, HEX HD, 1/4-20X/34 152370 2
13 SCREW, HEX HD CAP, 3/8-16 X 1 152507 2
14 WASHER, LOCK, SPLIT, 1/4 152591 2
15 SCREW, 1/4-20 X 1/2 HEX HEAD 152608 1
16 BOLT, 3/8-16 X 4 HEX HEAD TAP 152678 1
17 ELBOW, 1/4 NPT X 45 STREET 153869 1
18 NUT, HEX, TW 5/16-18 153942 6
19 NUT, 1/2-13 HEX 153943 1
20 ASSY, ARBOR, MK-2000 154636 1
21 SCREW, 5/16-18 X 3/8 SOCKET HEAD SET 157083 4
22 GRIP, HANDLE 7/8 ID 158608 1
23 SPRING, TORSION, 50 DEG 160069 1
24 GUARD, SPLASH 160310 1
25 SCREW, 5/16-18 X 1-3/4 HEX HEAD MACHINE 160948 6
26 PULLEY, 10J28 X 5/8 BORE 160949 1
27 PULLEY, 10J19 X .75 BORE 160950 1
28 BELT, 10J340 160925 1
29 ASSY, MOTOR MOUNT, MK-2000 160966 1
30 MOTOR, 1.5HP 60HZ 1725R.P.M. 1 PH 161099 1
31 ASSY, SWITCH BOX, 30AMP, LTF11 161101 1
32 FITTING, PUSH ON HOSE 1/4 X 1/4 MALE 165183 1
33 VALVE, BALL 1/4"M X 1/4"F 231248 1
34 CASTING, 2000, BLD GRD-COMP 150579G 1
Assy. Cutting Head, 1.5 HP, 14" Part # 170813
