MK-2000 ELECTRIC SAW PARTS LIST
ITEM DESCRIPTION PART # QTY.
1 PULLEY, 1A22 X 5/8" BORE 133140 1
2 PULLEY, 1A22 X 5/8" BORE 133157 1
3 HANDLE, BRICKSAW 139931 1
4 KEY, 3/16 SQ X 1-1/8 150344 1
5 STUD, BLD GUARD 150581 1
6 STRAP, MOTOR ADJ 150584 1
7 CASTING, 2000, BLTGRD INNR-COMP 150590 1
8 BLT GRD OUTR-COMP 150591 1
9 SCREW, HEX HD, CAP, 5/16-18X1-3/4 150919 2
10 WASHER, FLAT, SAE, 3/8 150923 1
11 BELT, AX32 151723 1
12 WASHER, LOCK, SPLIT, 5/16 151747 2
13 WASHER, FLAT, SAE, 5/16 151754 8
14 WASHER, FLAT, SAE, 1/4 151915 3
15 SCREW, HEX HD, 1/4-20X3/4 152370 2
16 SCREW, HEX HD CAP, 3/8-16 X 1 152507 2
17 WASHER, LOCK, SPLIT, 1/4 152591 2
18 SCREW, 1/4-20 X 1/2 HEX HEAD 152608 1
19 BOLT, 3/8-16 X 4 HEX HEAD TAP 152678 1
20 ELBOW, 1/4 NPT X 45 STREET 153869 1
21 NUT, HEX, TW, 5/16-18 153942 6
22 NUT, 1/2-13 HEX 153943 1
23 ASSY, ARBOR, MK-2000 154636 1
24 SCREW, 5/16-18 X 3/8 SOCKET HEAD SET 157083 2
25 KEY, 3/16 X 3/16 X 1-3/4 157561 1
26 GRIP, HANDLE 7/8 ID 158608 1
27 SPRING, TORSION, 50 DEG 160069 1
28 GUARD, SPLASH 160310 1
29 SCREW, 5/16-18 X 1-3/4 HEX HEAD MACHINE 160948 6
30 ASSY, MOTOR MOUNT, MK-2000 160966 1
31 FITTING, PUSH ON HOSE 1/4 X 1/4 MALE 165183 1
32 ASSY, 30A SWITCHBOX, LTF21 166022 1
33 MTR, 2HP 115/230V60HZ, NO SWITCH 231095-RW 1
34 VALVE, BALL 1/4"M X 1/4"F 231248 1
35 CASTING, 2000, BLD GRD-COMP 150579G 1
Assy. Cutting Head, 2 HP, 14" Part # 170815
