MKS TFT24 - 7.3 LAN Print Mode

7.3 LAN Print mode
1.Network Diagram
Features: Can control printer in LAN
3 .Software update
3.1 Copy the latest upgrade program to the SD card root directory, the motor can be renewed, upgrade
procedures include:
Mks_config.txt
Description
#wifmodel(0:MKS WIFI TFT 1:MKS HLK-WIFI)
>cfg_wifi_type:0
#wifi mode(0:sta;1:ap)
>CFG_WIFI_MODE 0
Set WiFi mode to STA mode
#wifi name
>CFG_WIFI_AP_NAME MKSWIFI
Set the WiFi name to the name of the
router you want to connect to
#wifi password
>CFG_WIFI_KEY_CODE MAKERBASE
Set the WiFi password to the router
password you want to connect to
#cloud service enable(0:disable 1:enable)
>cfg_cloud_enable:1
#cloud server url
>cfg_wifi_cloud_host:www.baizhongyun.cn
#cloud server port
>cfg_cloud_port:10086
It is recommended to disable the cloud
services,when LAN control.
Other parameters can be used by
default.
