Mobileye C2-270 - Section 9 Display Unit; 9.1. Left;Right Deviation Alert; 9.2. Pedestrian Forward Collision Alert; 9.3. Headway Visual Alert - (Car Icon)

16
2
1 1
3
9 9
4 55 4
8 7
6
Section 9
DisPlay Unit
A composite illustration, showing all C2-270 Display Unit icons, is presented in the
following figure.
9.1. Left/Right Deviation Alert
When a Lane Departure Warning is sounded, the Left or Right Deviation Alert
indicator will flash for 0.7 seconds.
9.2. Pedestrian Forward Collision Alert
Displayed only when a pedestrian or bicycle are detected ahead of you in the same
lane.
9.3. Headway Visual Alert - (Car Icon)
Displayed only when a vehicle is detected ahead of you in the same lane.
Colored green or red according to headway alert severity.
9.4. Headway Distance Meter
A two–digit number that displays the headway (in seconds) from the vehicle ahead.
Only values of 2.5 Headway seconds or less are displayed.
