D14D Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
1.6 Standard delivery
1.6.1 Standard delivery – D14D
Item Count Part Name
1.1 1 Camera housing
1.2 2 Lens (installed)
1.3 2 Lens mount
1.4 2 Lock ring (installed)
1.5 2 Sensor cable (integrated, not shown here)
1.6 1 Cable cover (installed)
1.7 2 Dome (1x transparent– integrated, 1x tinted)
1.8 1 Outer shell
1.9 1 Ethernet cable (installed)
1.10 1 Allen wrench 3mm
1.11 1 TX20 Torx wrench
1.12 1 Custom tool with magnet
1.13 1 MxBus connector (inserted):
1.14 1 MicroSD card, max. of 4 GB (inserted)
Installation accessories
Item Count Part Name
M.1.1 3 Dowels 8 mm
M.1.2 3 Stainless steel washers Ø 5.3 mm
M.1.3 3 Stainless steel wood 4.5x60 mm screws with TX20 head
2 lenses (item 1.2)
2 lens mounts (item 1.3)
2 lock rings (item 1.4)
Custom tool
with magnet (item 1.12)
Outer shell (item 1.8)
3 mm Allen wrench (item 1.10)
TX20 Torx wrench (item 1.11)
Camera housing (item 1.1)
Domes (item 1.7),
1x transparent, 1x tinted
Cable cover (item 1.6)
Ethernet cable (item 1.9)
