M15 Camera Manual: Product Overview
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
1.3.5 Sensor Modules L270-L320*
Item Number Part Name
4.1 1 Sensor module with axed washer
4.2 1 MOBOTIX lens L270-L320 (installed)
4.3 1 Protective lens cover (installed)
4.4 1 Cable retainer with bayonet catch (installed)
4.5 1 Sealing plug, blue, small (installed)
4.6 1 Nut (plastic)
*For an explanation of
the sensor module desig-
nations (e.g., L10‑L12),
please read
Section 1.2.1,
«M15 Lens Options»
Sensor module
4.1
4.4
4.5
4.2
4.6
4.3
