Preparing the Installation
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Furthermore, the “camera view from top to bottom” can also be achieved by installing the
camera on a wall or a pole at a tilt of 90°.
Note
Part of the captured image area is concealed behind the protective cover of the M15
housing, especially in the full image. For this reason, M15 cameras with L10-L12 lens
should be adjusted so that the concealed areas are not those that are supposed to
be monitored. The concealed area can be completely removed from the image by
panning/tilting/zooming the image using the virtual PTZ function.
Weatherproof housing visible in the
full image
Panning/tilting/zoom-
ing removes the area
concealed by the
weatherproof cover
