Jack Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
17
18
Attach 8x wedges (K) to the corners of the back panels [8] as shown,
and secure with 8x small screws (L).Attach 1x safety strap (V) to the
top panel [1] of the back side of the unit as shown using 1x washer (Z)
and 1x screw (W). Tighten with a screwdriver.
Insert the completed drawer into the main unit as shown, ensuring
they slide easily along the rails.
