Jack Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
1
2
Insert 8x bolts (C) into panel [1]. Tighten with a screwdriver.
Attach 1x slide rail (F) to panel [3] and secure with 3x screws (E).
Attach 1x slide rail (G) to panel [4] and secure with 3x screws (E).
Insert 4x bolts (C) to the panels [3] and [4]. Tighten with a screwdriver.
