Zara Two Door Cabinet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
Panel layout
1
Insert 6x bolts (C) into panel [1] and tighten with a screwdriver. Attach
2x brackets (P) to panel [1] and secure with 4x screws (E). Place 2x
cover (Q) over the bracket (P) as shown. Tighten with a screwdriver.
