Mocom Tethys H10 - Clean Chamber Filters

68
OPERATOR'S MANUAL
EN
CLEAN CHAMBER
FILTERS
Remove the basket from the washing chamber.
Remove the filters (1) and (2) on the bottom of the chamber ensuring that possible residues
do not drop inside the hole.
Rinse thoroughly the parts that compose filters (1) and (2) under running water and reposition
them in their housings.
NOTE
CORRECTLY PLACE FILTERS (1) AND (2) BACK IN THEIR RELEVANT
HOUSINGS.
NOTE
TO BE CLEANED, FILTER (1) DOES NOT HAVE
TO BE COMPLETELY DISASSEMBLED. SHOULD
FILTER BE DISASSEMBLED, RE-ASSEMBLE THE
O-RING AS SHOWN IN THE FIGURE.
