6) Waste water drain connection
The espresso machine drain is to be
connected by means of the included
reinforced plastic tubing. Connect one
end of the reinforced plastic tubing to the
drain hose connection on the left side of
the espresso machine, secure with included
hose clamp. Connect the other end to a
suitable waste water collection system.
In case such a system is not available,
drained liquids may be collected in a
suitable bucket and any necessary drain pipe
extensions shall be made using steel-lined
PVC tubing and suitable hose clamps.
Water specications table
Min. Max.
T.D.S. ppm 90 150
Total Hardness ppm 70 100
Total Iron (Fe
+2
/Fe
+3
) ppm 0 0,02
Free Chlorine (Cl
2
) ppm 0 0,05
Total Chlorine (Cl
2
) ppm 0 0,1
pH value 6,5 8,5
Alkalinity ppm 40 80
Chloride (Cl
–
) ppm not more 50
N.B.: Test water quality (the warranty is void if water parameters are not within the range
specied in the section “installation”)
