2. Denition of Available Models
This operating manual refers exclusively to the following models, of our own manufacture:
MODBAR AV, Espresso System
4 Digital Display
5 USB Key Connection
6 Power Switch
7 Selector
8 Pressure Gauge
9 Keypad
10 Drain
11 Water Inlet
12 Electrical Connection Pump
13 Power Inlet
14 Tap 1 Brewing
15 Tap 2 Brewing
16 Tap 1 Low Voltage
17 Tap 2 Low Voltage
18 Tap 1 High Voltage
19 Tap 2 High Voltage
20 Serial AUX Low Voltage
21 Scales Low Voltage
22 Precision Scale
Legend
Fig. 1 - ESPRESSO System
1
2 3
6
5
4
7
8
9
10
15
12
13
Espresso Tap
Espresso Module
14
11
16
17
20
18
19
21
22
ABR
For additional information on electronics,
keypads, and software programming,
please see the section entitled Software
Programming your Espresso Machine.
1 Espresso Actuator Lever
2 Selection Indicator
3 Timer
