modbar av Series - Installation Procedures

EN
11
3. Installation
THE DETAILS ON THE LEFT DESCRIBE
HOW TO CONNECT EACH WIRE TO THE PLUG.
RESPECT ALSO THE LOCAL SAFETY
REGULATIONS.
MODEL/SERIES
BOILER
GROUP
V/Hz
RATED
POWER
(W)
RATED
INPUT
(A)
MODULE
WATTAGE
TAP
WATTAGE
TOTAL
WATTAGE
POWER CORD
SIZE (mm²)
MODBAR AV
2 BOILER
1GR
A
C220-240V/50-60Hz
AC208/60Hz
2682,5 11,7 2131,5 551 2682,5
SEE ELECTRICAL
2252,5
1801 451,5 2252,5
CONNECTIONS
FOR DETAILS
WARNING
10,8
POWER CORD:
1 X BLUE (NEUTRAL)
1 X BROWN (PHASE)
1 X YELLOW & GREEN (GROUND)
3 X WIRES
220V
THE DETAILS ON THE LEFT DESCRIBE
HOW TO CONNECT EACH WIRE TO THE PLUG.
RESPECT ALSO THE LOCAL SAFETY
REGULATIONS.
MODEL/SERIES
BOILER
GROUP
V/Hz
RATED
POWER
(W)
RATED
INPUT
(A)
MODULE
WATTAGE
TAP
WATTAGE
TOTAL
WATTAGE
POWER CORD
SIZE (mm²)
MODBAR AV
2 BOILER
2GR
A
C220-240V/50-60Hz
AC208/60Hz
3233,5 11 2131,5 1102 3233,5
SEE ELECTRICAL
2703
1801 902 2703
CONNECTIONS
FOR DETAILS
WARNING
13
POWER CORD:
1 X BLUE (NEUTRAL)
1 X BROWN (PHASE)
1 X YELLOW & GREEN (GROUND)
3 X WIRES
220V
WARNING
In order to prevent cracks
or leakage: do not store or
install the Coffee machine
in places where in boiler or
hydraulicsystem to freeze.
WARNING
For the connection of the
machine, it must be provided a
suitable disconnection device
near the installation, so that
in case of trip, it is possible to
operate the device near the
machine.
