This operating manual refers exclusively to the following models, of our own manufacture:
MODBAR AV 2 groups, Espresso System
1 Espresso Tap 1
2 Espresso Tap 2
3 Tap 1 Brewing
4 Tap 2 Brewing
5 Tap 1 Low Voltage
6 Tap 2 Low Voltage
7 Tap 1 High Voltage
8 Tap 2 High Voltage
9 Tap 2 Coffee Boiler
10 Tap 1 Coffee Boiler
Legend
Fig. 1b - ESPRESSO System 2 groups
2
Espresso Taps
3
For additional information on electronics,
keypads, and software programming,
please see the section entitled Software
Programming your Espresso Machine.
Espresso Module
5
9
10
Barista Side
Barista Side
1
4
7
6
8
