Check the state of the packing and in the event
of damage, ask the delivery person to inspect
the goods.
Remove the protective film from the outer
panels. Use a suitable solvent to remove any
residual adhesive from the panels.
The overall dimensions of the appliance and the
position of connections are given on the
installation diagram at the end of this manual.
The appliance can be installed singly or in
combination with other appliances in the same
product range.
The appliance is not suitable for integrated
installation.
Position the appliance at least 10 cm from
adjacent walls.
If the appliance is to be be placed near walls,
dividers, kitchen furniture, decorative elements
etc. this must be made of non-combustible
materials
Otherwise, they must be covered with suitable
non-combustible heat insulating materials.
Level the appliance by means of the height-
adjustable feet
APPLIANCE ASSEMBLY WITH BASE, BRIDGE AND
CANTILEVER SOLUTIONS
Follow the instructions provided with the type of
support utilized.
FIXING THE APPLIANCE TO THE FLOOR
If the appliance is installed alone,
check if it needs to be fixed to a top or
to the floor. (TAB 5)
Secure the appliance to the floor one by one
using the adjustable feet, flanged or specific
bracket
For single models refer to the technical data
tables at the bottom of this manual and to the
Illustration section.
JOINING APPLIANCES TOGETHER IN LINE
Remove the control panels (A).
Remove the fixing screw nearest the panel from
eachof the sides to be joined (B).
Place the appliances side by side and adjust the
tops to the same height. (C)
Insert the (supplied) connector platein the seat
provided on the side of the top. Join the
appliances by screwing down the connector
plate using the the flat-headed M5 screws
(supplied). (D)
Turn one of the two internal tabs of the
appliances to be joined by 180°. (E)
Join the appliances by screwing the M5x40
screw on the opposite insert. (E)
Create a fumes exhaust system based on the "
Type " of appliance. The " Type " is stated on the
appliance dataplate.
Position the “A1” type appliance below an
extractor hood to ensure smoke and fumes
generated by cooking are removed.
Position the “B21” type appliance below an
extractor hood.
Fit the “B11” type appliance with a suitable fl ue,
available from the appliance manufacturer.
Follow the assembly instructions provided with
the flue.
Connect the flue to a 150/155 mm diameter
hose, heat resistant to 300°C.
Vent to the outside or into an effi cient fl ue. The
hose length must not exceed 3 metres.
The position and dimensions of connections are
given in the installation diagram at the end of
this manual.
