3) Unscrew the 2 screws blocking the control panel and disassemble the board as described in
the paragraph “replacing PC board” concerning failures and relative technical
interventions.
4) Place the machine on its side in order to be able to unscrew the screws at the bottom.
5) Place the machine back in the correct position and remove the upper and side sheet steel
cover, making sure not to pull the electric wires. Then remove the thermal insulation
without breaking it.
6) Unscrew the screws of the ceramic clamp of the heating element terminals. Repeat the
operation if you must replace more than one heating element mounted on the same
machine.
