RESEARCH AND DEVELOPMENT
10
7) Remove the heating element and mount the new one respecting the previous positioning.
Pay special attention to bend it carefully when positioning it in the curves in order not to
ruin its insulation. If the heating element is longer than necessary, cut it to measure
sheathing the end parts.
8) IMPORTANT: make sure that the tip of the probe is pushed into contact with the heating
element as shown in the photo below. The probe must remain at distance from the sheet
metal of the cavity.
9) Connect the terminals of the heating element to the ceramic clamps as it was originally.
10) Reposition the thermal insulation and close the machine by repeating the operations
described in points 1-2-3-4-5 in the opposite order.
- REPLACING CAVITY TEMPERATURE PROBE
terminals
