Moeller ps4-201-mm1 User Manual

Configuring and setting
parameters
39
04/99 AWB 27-1184 GB
Table 1: Station configurations
(m) = Master's configuration (s)=Slave's configuration
Table 2: Station parameters
a-d = See description of input/output data in the
table below
Master Intelligent slave SCO (from
ver. 05)
(m) (s)
Line 0 1 0 –
Station 0 1 to 8 0 –
Module 0 0 0 –
Master Intelligent slave SCO (from
ver. 05)
(m) (s)
Bus status Master – Slave SCO
Baud rate (kBaud) 187./375 – – 0.3 to 19.2
Protocol Suconet K/K1
(K1:
187.5 kBaud
only)
––Start bit
Stop bit
Data bit
Parity
Slave address – – 2 to 9 –
CRC Optional for
slaves
Optional
via
master
––
Input data
(Receive data)
–ac–
Output data
(Send data)
–bd–
Remote control – – Optional –
