Technical Data
81
04/99 AWB 27-1184 GB
Galvanic isolation Yes
Galvanic isolation between inputs No
Input status indication Yes (LEDs)
Terminals Plug-in screw terminals
Conductor cross-section
Flexible with ferrules 0.22 to 1.5 mm
2
Solid 0.22 to 2.5 mm
2
High-speed counter input I0.0
Clock frequency 3 kHz
Pulse shape Square
Pulse duration 50 %
Edge duration
≤
3 %
Alarm input I0.1
Analog inputs
No. 2
Signal range 0 V to 10 V
Total error Normally 0.8% of full scale
No. of conversions 1 ⫻ per cycle
Input resistance 20 k
Ω
Connection type of signal transmitter Two-wire connection to
transmitter
Digital representation of input signal 10 bits (1024 increments)
Setpoint potentiometers
No. 2
Value range 10 bits (1024 increments)
Adjustment With screwdriver
