Appendix
82
04/99 AWB 27-1184 GB
Outputs
No. of outputs 6
Rated voltage U
e
24 V DC
Permissible range 20.4 to 28.8 V DC
Polarity reversal protection Yes
Max. ripple
≤
5 %
Galvanic isolation
in groups No
Rated current I
e
For “1” signal 0.5 A DC for 24 V DC
Lamp load 4 W without series resistor
Utilization factor 1
Relative duty factor 100 %
Parallel connection of outputs
No. of outputs max. 4
Total maximum current 2 A
Total minimum current 250 mA
Residual current with “0” signal Approx. 140 µA
Short-circuit protection Yes, without set
Max. short-circuit release current 1.2 A over 3 ms per output
Off delay Normally 100 µs
Limiting of breaking voltage
With inductive loads Yes, –21 V (with U
N
= 24 V DC)
Operations per hour
With time constant
t
≤
72 ms
4800 (G = 1)
7500 (G = 0.5)
With time constant
t
≤
15 ms
18000 (G = 1)
Power supply
Polarity reversal protection Yes
Permissible range 20.4 to 28.8 V DC
Max. ripple ≤
5 %
