Moffat E31 - Page 16

-16-
Revision 2/F3506
FAULT POSSIBLE CAUSE REMEDY
NO THERMOSTAT HEATING
INDICATOR
Indicator faulty.
(Refer fault diagnosis 6.1.14)
Replace.
(Refer service section 6.3.3)
GRILL NOT WORKING
GRILL INDICATOR LIGHT NOT
WORKING
Element faulty / blown.
(Refer fault diagnosis 6.1.15)
Indicator faulty.
(Refer fault diagnosis 6.1.16)
Replace.
(Refer service section 6.3.14)
Replace.
(Refer service section 6.3.3)
ROAST TIMER (180 MINUTE)
WILL NOT TIME DOWN
NO HOLD INDICATOR
HOLDING TEMPERATURE
INCORRECT
Roast ’n’ Hold switch not
depressed.
No power to timer / timer faulty.
(Refer fault diagnosis 6.1.17)
‘Roast ‘n Hold’ switch faulty.
(Refer fault diagnosis 6.1.17)
Faulty indicator.
(Refer fault diagnosis 6.1.18)
Faulty timer.
(Refer fault diagnosis 6.1.18)
Hold thermostat set
temperature incorrect
Hold thermostat faulty.
(Refer fault diagnosis 6.1.19)
Depress switch. Switch will
illuminate.
Correct electrical fault / replace
timer.
(Refer service section 6.3.7)
Replace.
(Refer service section 6.3.4)
Replace.
(Refer service section 6.3.3)
Replace.
(Refer service section 6.3.7)
Adjust to correct temperature.
(Refer service section 6.4.4)
Replace.
(Refer service section 6.3.9)
DOOR DOES NOT CLOSE Tray in way of door.
Door seal obstruction.
Door handle installed
incorrectly.
Door ball catch setting incorrect.
Door pivot bushes / pins worn.
Correctly position tray in rack.
Correctly install door seal.
(Refer service section 6.3.20)
Fit correctly.
(Refer installation section)
Adjust.
(Refer service section 6.4.3)
Replace.
(Refer service section 6.3.21)
DOOR SEAL LEAKS Door seal damaged.
Door seal incorrectly fitted.
Door ball catch setting incorrect.
Door pivot bushes / pins worn.
Replace.
(Refer service section 6.3.20)
Correctly install door seal.
(Refer service section 6.3.20)
Adjust.
(Refer service section 6.4.3)
Replace.
(Refer service section 6.3.21)
