-6-
Revision 2/F3506
LOCATION
To ensure correct ventilation for the motor and
controls the following minimum installation
clearances are to be adhered to:
Rear 25mm / 1”
Left-hand side 25mm / 1”
Right-hand side 25mm / 1”
OVEN INTERNAL DIMENSIONS
Width 468 mm / 18.5”
Height 418 mm / 16.5”
Depth 432 mm / 17”
Oven Volume 0.08 m³ / 3.0 ft³
OVEN RACK SIZE
Width 460 mm / 18”
Depth: 370 mm / 14.5”
ELECTRICAL SUPPLY SPECIFICATION
OPTIONS
208 V AC 60 Hz, 14.6 A, 3.2kW @ 208 V
220-240 V AC 60 Hz, 13.0 A, 3.1kW @ 240 V
208-220 V AC 50 Hz, 14.6 A, 3.2kW @ 220 V
230-240 V AC 50 Hz, 13.0 A, 3.1kW @ 240 V
ELECTRICAL PLUG SPECIFICATION
REQUIREMENTS
Australia 3-pin 250V 15A, AS/NZ 3112
Canada 3-pin 250V 15A, NEMA 6-15
New Zealand 3-pin 250V 15A, AS/NZ 3112
United Kingdom 3-pin 250V 13A fused, BS
1363A
United States 3-pin 250V 15A, NEMA 6-15
Other Countries 3-pin 250V 13A minimum,
type to meet country stan-
dards
WATER SUPPLY CONNECTION
Max Pressure 550 kPa / 5.5 bar / 80 psi
Min Pressure 100 kPa / 1.0 bar / 15 psi
