Moffat E31 - Page 8

-8-
Revision 2/F3506
1
3
2
DOOR HANDLE INSTALLATION
1. Open oven door.
2. Remove two screws (item 2).
3. Remove the two screws (item 3) from the
handle (item 1).
4. Install the handle bracket through the slot
on the door side.
5. Screw in the two screws (item 2) fully, then
fully screw in the previous two screws (item
3). Ensure that they are tight.
Figure 2.2
Rating Plate
Figure 2.3
RATING PLATE LOCATION
The rating plate for the E31 convection oven is
located at the bottom left corner of the RH side
panel.
