Moffat Turbofan E27 - Page 32

Revision 3/F3563
© Moffat Ltd, August 2006 E27 Convection Oven
-32-
Pos Part No. Description
1 004914 OVEN – ENAMELLED
2 024393 WRAPPER
3 024381 LINTEL SUPPORT
4 004913 LINTEL – ENAMELLED
5 024405 SIDE SEAL ASSEMBLY
6 023219 HINGE COUNTER BRACKET
7 024410 OVEN ELEMENT 2800W – 240V
024409 OVEN ELEMENT 2800W – 208V
8 024433 OVEN FAN
9 024398 BAFFLE BRACKET TOP
10 024507 BAFFLE BRACKET BOTTOM
014031 STANDOFF
11 024526 BAFFLE
12 021698 BAFFLE SCREW
13 017770 PHIAL GUARD
14 024406 LEFT HAND SIDE RACK
15 023068 SIDE RACK SCREW
16 024408 OVEN RACK (NORTH AMERICAN MODEL)
16 025349 OVEN RACK (ALL OTHER MODEL)
17 024407 RIGHT HAND SIDE RACK
18 024413 TOP TRIM
(Refer Section 11.3 for E27MS Door Assembly)
19 021468 DOOR HANDLE (Refer Section 11.3 for E27MS Door Assembly)
20 024394 HANDLE STIFFENER (Refer Section 11.3 for E27MS Door Assembly)
21 024477 OUTER GLASS SEAL (Refer Section 11.3 for E27MS Door Assembly)
22 024377 DOOR OUTER GLASS
(Refer Section 11.3 for E27MS Door Assembly)
23 004919 GLASS CLAMP ANGLE (Refer Section 11.3 for E27MS Door Assembly)
24 024378 DOOR INNER GLASS (Refer Section 11.3 for E27MS Door Assembly)
25 024392 INNER GLASS SEAL
(Refer Section 11.3 for E27MS Door Assembly)
26 024414 BOTTOM TRIM (Refer Section 11.3 for E27MS Door Assembly)
27 004918 DOOR INNER PANEL
(Refer Section 11.3 for E27MS Door Assembly)
28 023218 HINGE
29 SA1550 CONTROL PANEL ASSEMBLY BAKBAR (REFER SECTION 11.2)
SA1549 CONTROL PANEL ASSEMBLY BLUE SEAL (REFER SECTION 11.2)
SA1551 CONTROL PANEL ASSEMBLY MOFFAT (REFER SECTION 11.2)
30 024394 OVEN BODY
31 013908 FOOT ASSEMBLY
32 024396 INSULATION PANEL
33 024503 MOTOR TIMER 208-220V
024567 MOTOR TIMER 220-240V
34 024504 MOTOR TIMER MOUNTING BRACKET
35 017185 CORDSET 15A – NZ/AUST
010162 POWERFLEX CORD 15A – EXPORT
017453 CORDSET 13A FUSED – UK
012206 CORDSET 15A – USA/CANADA
36 019213 SNAP BUSH 32mm
37 018251 CABLE ENTRY BRACKET
38 002138 CABLE CLAMP
002441 INSULATOR
39 013586 TERMINAL BLOCK
40 019238 SNAP BUSH 26mm
41 024505 RELAY 30A
42 024395 FOOT CHANNEL
43 024404 OVEN TOP/BOTTOM SEAL ASSEMBLY
44 024379 COVER PANEL
45 021637 MICROSWITCH BUTTON
021638 PIN CIRCLIP
46 044210 SPIRE CLIP
